Z-Type Tilting Bucket Elevator is a bucket conveying system designed to transport agricultural products such as pulses, seeds, and wheat, as well as fragile industrial raw materials, simultaneously along horizontal and 90° vertical axes in facilities with limited space, without damaging the product and with the capability of discharging at multiple points.
Working Principle: The system operates with specially designed buckets attached to an endless chain system running along sprockets. The buckets receive the product from homogeneous feeding units, transport it vertically, and discharge it by tipping at the designated discharge point:
Multi-Point Pneumatic Discharge: Pneumatic components, air lines, and dedicated automation enable product discharge at multiple points along a single line.
Gentle and Safe Conveying: The buckets interlock at the intake point to prevent product leakage and rotate using their own weight or dedicated mechanisms at the discharge point, transferring fragile materials without damage.
Balanced and Homogeneous Feeding: To maintain a constant flow, the system is typically integrated with vibratory feed hoppers, while product collection chutes are used for controlled and regular processes.
Enclosed and Modular Construction: The dust-tight enclosed body features a fully bolted modular design, offering flexible bucket volume options and easy dimensional modifications.
